Latest News: Development of a remote timer for "drive shoot drive"

index1

Connection Tripod / Dolly

Respectively at the ends and in the centre, the guide rails have a one-quarter inch (on request three-quarters inch) thread and so are coupeable to every quick-release plate commercially available.

index2

Connection Camera / Dolly

At the top side, there is a three-eights thread screw, where every tripod/video head may be screwed on. The Video head
is not included.



Realtime Animation
Push the buttons

Content on this page requires a newer version of Adobe Flash Player.

Get Adobe Flash player

technical details
All for the 100 cm Version

Weight
Including dolly, control unit and batteries:
3.5 kg (8.0 pounds)

Size
Width: 100 cm (39,37 inches)
Height: 6 cm (2,36 inches)
Depth: 11 cm (4,33 inches)

Power
The energy comes from eight commercially
available AA batteries. In "Drive Shoot Drive" mode,
the batteries (eneloop) run for ten hours,

Material
The housing of the dolly is made of aluminium,
CNC-milled. The surface has a black powder
coating.



index3

Main Controller

The control system and battery are combined in one device. The speed is infinitely adjustable. Clockwise/left-handed rotation. The energy comes from eight commercially available AA batteries. n "drive shoot drive" mode, the number of steps /photos is adaptable via potentiometer. Minimum number of steps / photos referred to 100cm is 300, maximum 4000.
index10

Remote Timer

The timer is connected to the main controller. The stop time is adjusted via a potentiometer. The stop time is the time stopped by the dolly between the individual photos. The shortest stop time is two seconds, the longest 2 min. The camera is automatically actuated after every stop.

Maximum Load

The slider may be operated in a horizontal, vertical and overhead way. The maximum camera weight in horizontal operation is approx. 6 kg (13 lbs), in vertical/diagonal function approx. 3,5 kg (7.7 lbs) (including head).



Finally

The Slider offered here has developed from a DIY project. It was my idea to build a compact and light-weight dolly that is easy to carry in a backpack and on journeys. The ‘75 version suits diagonally in a suitcase and thus is ideal for air travels as well.

At present, Pocketslider is still a one-man company. The sliders are built by myself in little series per month. Due to the increased demand longer waiting times cannot be excluded.



Supported Cameras

Nikon MC-30

Nikon D800, D700, D300, D300s, D200, D100 (battery grip required), D3s, D3X, D3, D2X, D2Xs, D2H, D2Hs, D1X, D1H, D1
Nikon F6, F5, F90X, F100, MC-30
Fuji S3 Pro, S5 Pro; Kodak DCS Pro


Nikon DC1

Nikon D80, D70s

Nikon DC2

Nikon D90, D7000, D5100, D5000, D3100


Canon N3

Canon EOS 50D, 40D, 30D, 20D, 10D, 7D, 5D, 5D Mark II, 5D MarkIII
Canon EOS 1D, 1Ds, 1D Mark II, 1Ds Mark II, 1D Mark II N, 1D Mark III, 1Ds Mark III, 1D Mark IV



Canon E3



Canon RS-60E3, Pentax SC-205, CS-205
Canon EOS 60D, 1100D, 1000D, 600D, 550D, 500D, 450D, 400D, 350D, 300D, 300Dx, 300V, 300, 3000 etc.
Canon Powershot G12, G11, G10
Canon EOS 30, 30v, 33, 33v, 50, 50E etc.
Canon EOS 500, 5000 etc.
Pentax K-7, K-5, K200D, K20D, K110D, K100, K10D, istD, istDs, istDL, MZ-6, ZX-L, MZ-L
Samsung GX-10, GX-1L, GX-1S, GX-20


Panasonic DMW-RS1

Panasonic Lumix DMC FZ100, FZ50, FZ30, FZ20, L1, LC10, LC1, G1, G2, G3, GH1, GH2, GF1, G10
DMW-RS1, DMW-RS1E, DMW-RSL1


Olympus RM-UC1

Olympus RM-UC1
Olympus E-620, E-600, E-520, E-510, E-450, E-420, E-410, E-400, E-30
Olympus SP-590UZ, SP-570 UZ, SP-565 UZ
Pen EP-1, EP-2, EP-3, E-PL2, E-PL3
NOT for Pen E-PL1


Olympus RM-CB1

RM-CB1
E1, E10, E20, E100RS, E20M
E-5, E-3, E-1, E-10, E-20
with battery grip also: E-300, C-5060, C-8080, C-7070)


Sony RM-S1AM

Sony RM-S1AM, Minolta RC-1000S, RC-1000L
Sony a900, a850, a700, a580, a560, a550, a500, a450, a350, a300, a200, a100, a77V, a65V, a55, a33
Minolta 7D, 5D
